Specifications
| Model | ZJY1.0-6.0×1600(2000) | ZJY2.0-10.0×1600(2000) | ZJY3.0-12.0×2000 | ZJY4.0-16.0×2000(2500) | |
| Coil Material | Cold-rolled Coil,Hot-rolled Coil,Stainless Coil,Galvanized Coil | ||||
| Coil Thickness | 1.0～6.0mm | 2.0～10.0mm | 3.0～12.0mm | 4.0～16.0mm | |
| Coil Width | 700～1600(2000) mm | 800～1600(2000) mm | 800～2000 mm | 800～2000(2500) mm | |
| Coil Weight | ≤25T | ≤25T(30T) | ≤30T | ≤30T | |
| Coil I.D | Φ508mm Φ610mm Φ760mm | Φ508mm Φ610mm Φ760mm | Φ508mm Φ610mm Φ760mm | Φ610mm Φ760mm Φ820mm | |
| Coil O.D | ≤Φ2000mm | ≤Φ2000mm | ≤Φ2000mm | ≤Φ2000mm | |
| Strip Width | ≥55mm | ≥65mm | ≥85mm | ≥85mm | |
| Number of Strip | 5～15 | 5～15 | 4～15 | 4～12 | |
| Slitting Accuracy | ≤±0.25mm | ≤±0.25mm | ≤±0.3mm | ≤±0.3mm | |
| Line Speed | 0～60m/min | 0～30m/min | 0～30m/min | 0～20m/min | |
